The Ultra Light BD-9024 Linear In-Ground Light is a professional architectural lighting solution designed to provide precise, focused, and comfortable outdoor illumination. Its sleek trimless recessed design integrates cleanly into the ground, while the anti-glare optical system helps reduce unwanted glare and creates a refined lighting effect.

One of the key features of the BD-9024 is its narrow 13° beam angle, which produces a highly directional and concentrated beam of light. This makes the fixture especially suitable for highlighting building facades, columns, architectural details, walls, entrances, landscape features, and other vertical surfaces where controlled illumination is required.

The combination of the 13° focused beam and anti-glare lens design allows the light to be directed precisely toward the intended surface while minimizing unnecessary light spill. This creates a cleaner architectural lighting effect and helps emphasize textures, materials, and structural details.

Designed for recessed in-ground installation, the BD-9024 features a durable aluminum housing with a clear glass diffuser. Its IP67 protection rating provides resistance against dust and water, while the IK08 impact resistance enhances durability for demanding outdoor environments.

The fixture is powered by premium CREE / LUMILEDS LED chips, providing stable and efficient illumination with a rated lifespan of up to 25,000 hours. It is available in 12W, 20W, and 38W versions, allowing the appropriate light output to be selected according to the size and requirements of the project.

Two color temperature options are available: 2200K for an extra-warm architectural atmosphere and 3000K for warm, comfortable illumination. This makes the BD-9024 particularly suitable for villas, hotels, resorts, commercial buildings, landscape projects, and contemporary architectural applications.

Key Features

• Clean trimless linear in-ground design.

• Narrow 13° directional beam angle for precise and focused illumination.

• Anti-glare optical lens design for improved visual comfort.

• Ideal for highlighting walls, facades, columns, and architectural details.

• IP67 protection against water and dust.

• IK08 impact resistance for enhanced durability.

• Durable aluminum housing with clear glass diffuser.

• CRI 80 for natural color appearance.

• Premium CREE / LUMILEDS LED chips.

• Available in 12W, 20W, and 38W.

• Available in 2200K and 3000K color temperatures.

• Operating voltage: 100–240VAC, 50/60Hz.

• Rated lifespan up to 25,000 hours.

• Operating temperature from -20°C to +55°C.

• Black finish.

• 3-year warranty.


Technical Specifications

• Model: BD-9024

• Type: Linear In-Ground Light

• Input Voltage: 100–240VAC

• Frequency: 50/60Hz

• Beam Angle: 13° – Narrow / Directional Beam

• Color Rendering Index: CRI 80

• Power Factor: 0.5 for 12W, 0.9 for higher wattages

• Protection Rating: IP67

• Impact Resistance: IK08

• Housing Material: Aluminum

• Cover Material: Clear Glass

• Available Color: Black

• Operating Temperature: -20°C to +55°C

• Switching Cycles: 12,500

• Lifespan: 25,000 Hours

• Warranty: 3 Years


Power & Light Output Options

• 12W – 2200K: 960 lumens

• 12W – 3000K: 960 lumens

• 20W – 2200K: 1600 lumens

• 20W – 3000K: 1600 lumens

• 38W – 2200K: 3040 lumens

• 38W – 3000K: 3040 lumens


Dimensions

BD-9024-12W

Cut-out Size: 980 × 51.6 mm

Length: 300 mm

Width: 50 mm

Height: 75 mm

Weight: 3100 g

BD-9024-20W

Cut-out Size: 1980 × 51.6 mm

Length: 1000 mm

Width: 50 mm

Height: 75 mm

Weight: 5960 g

BD-9024-38W

Length: 1000 mm

Width: 50 mm

Height: 75 mm

Applications

The focused 15° directional beam makes the BD-9024 especially suitable for:

• Building facades and architectural elevations.

• Columns and vertical architectural elements.

• Exterior walls and textured surfaces.

• Villa and building entrances.

• Gardens and landscape features.

• Pathways and walkways.

• Hotels and resorts.

• Residential and commercial projects.

• Focused architectural accent lighting.


Why Choose This Product?

The BD-9024 combines a clean trimless appearance with a precise 15° directional beam and anti-glare optical design, making it an excellent choice when the goal is not simply to illuminate an area, but to direct light exactly where it is needed.

Its narrow beam helps create defined lines of light and highlight architectural surfaces and details, while IP67 and IK08 protection, durable aluminum construction, and a 3-year warranty make it suitable for professional outdoor lighting projects.
